COLARIS-NF.PRINTER
| DIGITAL INKJET PRINTING
Characteristics and Technology
COLARIS-NF
- COLARIS-NF: using Dimatix StarFireTM SG1024 print heads with different nozzle sizes
- up to 8 colors of different ink types
- Prints different colors or patterns on both sides in one pass
- Suitable inks: pigment, acid, disperse, reactive, sublimation or VAT (depending on the type of fabric)
Applications
- Printing on Narrow Fabrics made out of PES, PA, CO etc.
- Non-elastic and elastic tapes
- Satin
- Taffeta
- Decoration tapes
- Packing tapes
- Ribbons
- Belts and seat belts
- Velvet
- Zippers
- Touch-and-close fasteners
- Medical tapes
- Fiberglass tapes
- Technical tapes
Technical Data
COLARIS-NF |
|||
| Specification | COLARIS-NF | COLARIS-NF | |
| Printhead type | Dimatix StarFireTM | Dimatix StarFireTM | |
| Max. printing width | 65 mm | 250 mm | |
| Number of colors | up to 8 | up to 8 | |
| Heads per color | 1 | up to 4 | |
| Number of printheads | up to 16 SG1024 XSA, SA, MA |
up to 64 SG1024 XSA, SA, MA |
|
| Drop sizes |
7-75 pl |
7-75 pl |
|
| Max. printing speed | up to 50 m/min | up to 50 m/min | |
| Suitable inks |
pigment |
pigment reactive acid disperse sublimation VAT |
|
